DCN Switch L2 48x 10 / 100 / 1000Base-T RJ45 + 4x 100 / 1000Base-X SFP, S4600-52P-SI DCN

10/100/1000 Base-T (RJ45) ports

48

100/1000 Base-X (SFP) ports

4

Performance

Switching matrix

104 Gbps

Data transfer rate

78 Mpps

Packet Buffer

3 MB (2x 1,5 MB)

JUMBO Frame

12 K

Number of VLANs

4 K

MAC address table

16 K

Multi-broadcast support

1 K

MAC address table additional information

Shared MAC address array for unicast and multicast (1:1 ratio)

ACL Table

2 K

Number of Vlan Interfaces (IP)

16

CPU Clock

800 MHz

Flash memory

32 MB

RAM memory

128 MB

Features

Enhanced Accessibility Features

IEEE 802.1D (STP), IEEE 802.1w (RSTP), IEEE 802.1 s (MSTP), IEEE 802.3 ad LACP, Virtual Cable Testing, DDM, LLDP, Loop Guard, ERPS (ITU-T G.8032)

Traffic control

IEEE 802.1Q, Port-based VLAN, Protocol-based VLAN, IP Subnet-based VLAN, Voice VLAN, MAC VLAN, Source/Destination IP LACP Algorithm (Load Balancing), GVRP, IEEE 802.1ad Vlan Stacking (QinQ), Selective QinQ, Flexible QinQ

Security

Layer 2 MAC filtering, BPDU Tunnel, Radius and Tacacs+ login authentication and authorization, Tacacs+ accounting/auditing, SSH v1/v2, DHCP/DCHPV6 Snooping, IP/IPv6 Source Guard, Port Security

QoS

IEEE 802.1p Priority Queues per Port (8 Queues), IEEE 802.1p Quering method, Trusted COS/TOS/IP Precedence/DSCP/Port number, Broadcast Storm Control, Rate Limiting, port based, Quering method - Strict priority/ Weighted Round Robin/ Weighted Deficit Round Robin Ścisły priorytet w Weighted Round Robin

Multiemisja L2/L3

Multicast VLAN, IGMP v1,v2, v3, IGMP Query, IGMP Snooping (v1/v2/v3), IGMP Snooping Fast Leave (v2,v3), IPv6 MLD v1/v2 Snooping

L3 IPv6

IPv4/IPv6 Dual Protocol Stack, IPv6 address

Management

Console port RS-232 (RJ45), GUI (Web), Telnet, SNMP v1/v2c/v3, TFTP/FTP, Configuration backup and restore, Multi-level CLI, DHCP Client/Relay/Server, DHCP relay per VLAN, DHCP option 43/60/82, DHCPv6 option 37/38, DHCPv6 Relay/Server, SNTP/NTP SP, sFlow, Port Mirroring for IP/TCP/UDP, RSPAN, IEEE 802.3ah EFM, IEEE 802.1ag CFM

MIB

RFC 1066 TCP/IP-based MIB, RFC1213, 1157 SNMPv2c/v3 MIB, RFC1493 bridge MIB, RFC 2674 bridge MIB extension, RFC1643 ethernet MIB, RFC1757 RMON group 1/2/3/9, RFC 2925 Remote Management MIB, RFC 2233 (rfc2233) - SMIv2 MIB

Electric

Power Supply

230 V AC

Maximum power consumption

? 40 W
